Overview

BlockchainBench is structured as four OSGi bundles under the Eclipse Plug-in Development Environment (PDE). Each bundle is a self-contained module with an explicit MANIFEST.MF that declares what it exports and what it requires. The design keeps a strict one-directional dependency flow: front ends depend on the core engine and the shared models, the core engine depends on the shared models and the Palladio platform, and the shared models depend on nothing inside the project.

Bundle dependencies

flowchart TB
  Desktop["org.blockchainbench.desktop"]
  Server["org.blockchainbench.server"]
  Core["org.blockchainbench.core"]
  Utils["org.blockchainbench.utils"]
  Palladio["Palladio blockchainsystems<br/>bscm, core, threesim, doublespending, plugin, loggers"]
  Mdsd["tools.mdsd standalone init"]
  EMF["Eclipse / EMF runtime"]
  Gson["com.google.gson"]
  Log4j["org.apache.log4j"]

  Desktop --> Core
  Desktop --> Utils
  Server --> Core
  Server --> Utils
  Core --> Utils
  Core --> Palladio
  Core --> Mdsd
  Core --> Log4j
  Utils --> Gson
  Utils --> Log4j
  Palladio --> EMF
  Mdsd --> EMF

Core is the only bundle that references Palladio types. This is deliberate: the front ends and the shared models remain free of simulator dependencies, which keeps them small, fast to compile, and portable across front ends.

The provided interface

The single seam between the front ends and the engine is IBlockchainBench, exported from the org.blockchainbench.core.simulation package. Both the desktop and the server bundle import exactly that package and program against the interface, never against SimulationHandler directly (except at the one point where they instantiate it).

flowchart LR
  Desktop -->|uses| I(("IBlockchainBench"))
  Server -->|uses| I
  I -.implemented by.-> Handler["SimulationHandler"]

Threading model

Concurrency is intentionally minimal, because the underlying EMF and Palladio machinery is not thread-safe.

• SimulationHandler owns a single-threaded executor named simulation-worker. Every submitted group is processed sequentially on that one daemon thread, giving a strict FIFO queue and eliminating EMF concurrency hazards.
• submit(...) returns immediately with a simulationId; the actual work happens on the worker. Status and results are published through thread-safe fields on SimulationInfo (volatile status, CopyOnWriteArrayList results).
• Front ends observe progress by polling getSimulation(id). In the desktop this poll runs on the JavaFX application thread via a one-second Timeline; any UI update triggered from background work is marshalled back with Platform.runLater.

Runtime and platform context

The engine runs inside an Eclipse Equinox runtime and drives Palladio in standalone mode. Before any simulation, AbstractStandaloneSimulator initialises the standalone environment through the tools.mdsd standalone-initialisation library, which registers project URIs and configures logging.

Two consequences of this platform are worth knowing:

• The tools.mdsd log4j initialisation task calls BasicConfigurator.resetConfiguration() and installs a single console appender. It runs once per simulator mode, as part of the cached initialisation. Anything that wants to attach its own log4j appender must do so after that step, because the reset removes all previously registered appenders.
• Part of the simulator’s progress output is written straight to System.out by the Palladio library (for example the Monte-Carlo progress messages), independently of log4j. A front end that wants to mirror the full console output therefore has to observe System.out, not only the log4j stream.

Application entry points

Both runnable bundles contribute an Eclipse application through plugin.xml:

• Desktop: the application class is org.blockchainbench.desktop.Launcher, which boots the JavaFX application.
• Server: the application class is org.blockchainbench.server.SimulationApplication, which runs a batch and exits.

These are launched with an Eclipse Application run configuration. See Build and run for the practical steps and the required data layout.
